Arduino LoRa Weather Sensor

/**

 * LoRa Weather Client

 *

 * Author: Shawn Hymel

 * Date: March 23, 2019

 *

 * Transmits temperature, humidity, and pressure data over raw

 * LoRa radio. Reads data from BME280 sensor and transmits with

 * following packet:

 *

 * | 1B From Addr | 1B To Addr | 2B Temp | 2B Humd | 2B Pres |

 *

 * Note that temperature, humidity, and pressure values are

 * scaled up by 10 and rounded to nearest integer before being

 * sent. The server will need to scale received values by 1/10.

 * This is to avoid sending full floating point values.

 *

 * Required libraries:

 *  - http://www.airspayce.com/mikem/arduino/RadioHead/ (v1.59)

 *  - https://github.com/adafruit/Adafruit_Sensor

 *  - https://github.com/adafruit/Adafruit_BME280_Library

 *

 * License: Beerware

 */


#include <Wire.h>

#include <SPI.h>


#include <Adafruit_Sensor.h>

#include <Adafruit_BME280.h>

#include <RH_RF95.h>


#define DEBUG 0


// Parameters

const uint8_t LORA_NODE_ADDR = 0x01;    // This node's address

const uint8_t LORA_SERVER_ADDR = 0x00;  // LoRa receiving address

const int WAIT_TIME = 3000;             // ms

const int TX_BUF_SIZE = 8;              // Transmit buffer size

const float RFM_FREQ = 915.0;           // Frequency for RFM95W

const int RFM_TX_POWER = 17;            // 5..23 dBm, 13 dBm is default


// Pins

// SPI:

// MOSI = 10

// MISO = 12

// SCK = 13

const int RFM_RST_PIN = 2;

const int RFM_INT_PIN = 3;

const int RFM_CS_PIN = 4;

const int BME_CS_PIN = 10;


// Instance of radio driver over SPI

RH_RF95 rfm(RFM_CS_PIN, RFM_INT_PIN);


// Communicate with BME280 over SPI

Adafruit_BME280 bme(BME_CS_PIN);


// Transmit buffer

uint8_t tx_buf[TX_BUF_SIZE];


void setup() {


#if DEBUG

  Serial.begin(9600);

#endif


  // Manually reset RFM95W

  pinMode(RFM_RST_PIN, OUTPUT);

  digitalWrite(RFM_RST_PIN, HIGH);

  delay(100);

  digitalWrite(RFM_RST_PIN, LOW);

  delay(10);

  digitalWrite(RFM_RST_PIN, HIGH);

  delay(10);


  // Initialize RFM95W

  if ( !rfm.init() ) {

#if DEBUG

    Serial.println("Could not initialize RFM95");

#endif

    while(1);

  }

#if DEBUG

  Serial.println("RFM95 initialized");

#endif


  // Set RFM95W frequency

  if ( !rfm.setFrequency(RFM_FREQ) ) {

#if DEBUG

    Serial.println("Could not set frequency on RFM95");

#endif

    while(1);

  }

#if DEBUG

  Serial.print("RFM95 frequency set to ");

  Serial.print(RFM_FREQ);

  Serial.print(" MHz");

#endif


  // Set RFM95W transmit power from PA_BOOST pin

  rfm.setTxPower(RFM_TX_POWER, false);


  // Initialize BME280

  if ( !bme.begin() ) {

#if DEBUG

    Serial.println("Could not find BME280 on SPI bus");

#endif

    while(1);

  }

#if DEBUG

    Serial.println("BME280 initialized");

#endif

}


void loop() {



  // Read data

  float temp = bme.readTemperature();

  float humd = bme.readHumidity();

  float pres = bme.readPressure() / 100.0;



  // Scale (x10) and round data

  int16_t tempt = (int16_t)((temp * 10.0) + 0.5);

  int16_t humdt = (int16_t)((humd * 10.0) + 0.5);

  int16_t prest = (int16_t)((pres * 10.0) + 0.5);


#if DEBUG

  Serial.print("Temperature: ");

  Serial.print(temp, 1);

  Serial.println(" C");

  Serial.print("Humidity: ");

  Serial.print(humd, 1);

  Serial.println("%");

  Serial.print("Pressure: ");

  Serial.print(pres, 1);

  Serial.println(" hPa");

#endif



  // Stuff buffer

  tx_buf[0] = LORA_NODE_ADDR;     // From address (this node) [1 byte]

  tx_buf[1] = LORA_SERVER_ADDR;   // To address (server) [1 byte]

  tx_buf[2] = (0xff & tempt);     // Temperature [2 bytes] little-endian

  tx_buf[3] = (0xff & (tempt >> 8));

  tx_buf[4] = (0xff & humdt);     // Humidity [2 bytes] little-endian

  tx_buf[5] = (0xff & (humdt >> 8));

  tx_buf[6] = (0xff & prest);     // Pressure [2 bytes] little-endian

  tx_buf[7] = (0xff & (prest >> 8));


#if DEBUG

  Serial.print("Sending buffer:");

  for ( int i = 0; i < TX_BUF_SIZE; i++) {

    Serial.print(" 0x");

    Serial.print(tx_buf[i], HEX);

  }

  Serial.println();

  Serial.println();

#endif


  // Send data to server

  rfm.send(tx_buf, TX_BUF_SIZE);

  rfm.waitPacketSent();


  delay(WAIT_TIME);

}

pip install adafruit-circuitpython-rfm9x

# LoRa Weather Server
#
# Author: Shawn Hymel
# Date: March 23, 2019
#
# Receives and display temperature, humidity, and pressure data from raw LoRa
# radio. Run with lora-weather-client.ino on Arduino.
#
# Required packages:
#  pip install adafruit-circuitpython-rfm9x
#
# License: Beerware

import time
import busio
from digitalio import DigitalInOut, Direction, Pull
import board
import adafruit_rfm9x

# Configure RFM9x LoRa Radio
CS = DigitalInOut(board.CE1)
RESET = DigitalInOut(board.D25)
spi = busio.SPI(board.SCK, MOSI=board.MOSI, MISO=board.MISO)

# Attempt to set up the RFM9x module
try:
    rfm9x = adafruit_rfm9x.RFM9x(spi, CS, RESET, 915.0)
    print('RFM9x detected')
except RuntimeError:
    print('RFM9x error')


# Wait for LoRa packets
while True:
    packet = None
    packet = rfm9x.receive()
    if packet != None:

        print("Received:",  str(packet))

        # Split packet
        from_addr = packet[0]
        to_addr = packet[1]
        temp = int.from_bytes(packet[2:4], byteorder='little') / 10.0
        humd = int.from_bytes(packet[4:6], byteorder='little') / 10.0
        pres = int.from_bytes(packet[6:8], byteorder='little') / 10.0

        # Print results
        print("From:", from_addr)
        print("To:", to_addr)
        print("Temperature:", temp, "C")
        print("Humidity:", humd, "%")
        print("Pressure:", pres, "hPa")
        print()
