Replace the Shunt

Discover Allegro’s magnetic current sensors to make your design challenges easier

Technology advancements and the evolution of magnetic current sensors over the last two decades have made them a compelling alternative to traditional shunt-based current sensing circuits. With greater efficiency and isolation, higher bandwidths, smaller size and improved overall performance, engineers and designers can quickly and easily integrate these sensors into their electronic systems.

Packaging Innovation: Designers and engineers face the ongoing challenge of creating electronic systems that are both compact and energy-efficient. Allegro's innovative packages, featuring integrated shunt-less sensor solutions, directly address this challenge. By eliminating the need for external shunt resistors and other discrete components, designers and engineers can achieve significant reductions in both component count and overall circuit size while improving efficiency.

  • Compact design: The integrated magnetic current sensors are significantly smaller, saving valuable board space and reducing the number of components on the bill of materials.
  • Lower heat dissipation: The lower conductor resistance of integrated magnetic current sensors’ lead frames result in cooler system temperatures.
  • Simplified design process: By integrating the functionality of a traditional shunt resistor circuit into a single package, Allegro’s technology simplifies component placement and streamlines the design process.

Related Content

An image of a server farm

Video: ACS37220 Product Overview

The ACS37220 is a magnetic current sensor designed to replace high-power sense resistors in high-current monitoring applications requiring an isolation voltage below 100V. Compared to shunts, this device provides a smaller footprint, higher efficiency and simpler integration.

Person reviewing design on a computer

Article: Overcoming Size Challenges in PCB Design with Magnetic Current Sensors

Magnetic current sensors provide a compact and efficient alternative to traditional current measurement techniques that significantly reduce the size of components on PCBs, crucial for space-constrained electronic designs.

PCB printing facility

Article: Next-Generation Current Measurement: Addressing PCB Design Challenges with Magnetic Current Sensors

Introducing the Next-Generation Current Measurement Series: Advanced magnetic current sensors accurately detect magnetic fields generated by current flow, offering precise current level measurements.

  • ACS37220
  • ACS711
  • ACS71240
  • Eval Board

The ACS37220 is a high-power-density 200A, 150kHz magnetic current sensor for applications requiring an isolation voltage below 100V.

The ACS711 is a Hall-effect linear current sensor with overcurrent fault output for <100 V isolation.

The ACS71240 is a current sensor IC with common-Mode field rejection and overcurrent detection.
