EdgeLine® High-Speed Edge Card Connectors

With the Molex EdgeLine® High-Speed Edge Card Connectors, you get a low-profile edge card that now supports data transmission speeds up to 25 gigabits per second. The EdgeLine® connectors are available in multiple orientations and PCB thicknesses for use in high-speed signal transmissions and high-density signal applications such as: Storage systems found in telecommunications hardware; wireless infrastructure to support 4G and LTE protocols and networking equipment. Edge card solutions have exploded in popularity with the proliferation of PCIe busses, particularly as customers continue to require higher data rates with superior signal integrity all within a limited amount of PCB space. The EdgeLine® Connector System addresses these needs for high-speed applications with this small one-piece solution, supporting edge cards with various PCB thicknesses and a narrow connector profile to improve airflow in convection cooled system environments.
