Embedded Processing Units (EPUs)

Simplify your Embedded Computer Search

The Flexible Embedded Computers

Today embedded computer boards come in all shapes and sizes, so why is it so hard to select one for your application? New applications demand more performance, have power and heat constraints, need higher levels of reliability, and have to fit into a budget. That doesn’t make the selection process simple.

VersaLogic’s new EPU embedded computers can put the "easy" back into the selection process. The key is flexibility.

EPUs offer a long list of advantages over other embedded computer board products, including:

  • Flexibility. The two-board concept allows many CPU and I/O combinations to be created for a wider range of products.
    Get the performance, power draw, and I/O combination that you need!
  • Faster Time-To-Market. All EPU configurations are fully assembled, tested, and production ready. Buy one off-the-shelf today! Build your prototype tomorrow!
  • Very small footprint. The two-board concept allows EPUs to be 1/2 the size of single board computers!
  • Modifiable. The two-board concept allows both minor and major I/O modifications at a much lower cost, and shorter lead time.

There are many more advantages, including being almost obsolescence proof. On top of VersaLogic’s standard 5 year availability guarantee and Product Life Extension programs, EPUs support easier technology migration. Migrate to an EPU with a newer CPU module, but keep your existing I/O configuration and connectors for drop-in compatibility. That’s easy migration!

EPUs are currently offered with 8 CPU choices (performance levels) and 6 I/O configurations. Select from some of the popular in-stock models below. Built-to-order configurations are also available. For more details on the EPU concept click here.

VL-EPU-3310
  Power and Size optimized Graphics and Video optimized

VL-EPU-3310

  • Smallest size
  • SWaP

VL-EPU-3311

  • Small size
  • More I/O
  • SWaP

VL-EPU-3312

  • Medium size
  • Good I/O
  • TPM

VL-EPU-4460

  • Medium size
  • Good I/O

VL-EPU-4462

  • Larger size
  • High I/O
  • TPM

VL-EPU-4562

  • Larger size
  • High I/O
  • TPM
BayTrail
Atom E3815 1.6 GHz
Single-Core

2 GB RAM

Datasheet VL-EPU-3310View VL-EPU-3310 Product Training ModulesXX Product Page

2 GB RAM

Datasheet VL-EPU-3311View VL-EPU-3311 Product Training ModulesVL-EPU-3311 Product Page

2 GB RAM

Datasheet VL-EPU-3312View VL-EPU-3312 Product Training ModulesVL-EPU-3312 Product Page


BayTrail
Atom E3827 1.75 GHz
Dual-Core

2 GB RAM

Datasheet VL-EPU-3310VL-EPU-3310 Product Page

2 GB RAM

Datasheet VL-EPU-3311View VL-EPU-3311 Product Training ModulesVL-EPU-3311 Product Page

2 GB RAM

Datasheet VL-EPU-3312View VL-EPU-3312 Product Training ModulesVL-EPU-3312 Product Page


BayTrail
Atom E3845 1.91 GHz
Quad-Core

4 GB RAM

Datasheet VL-EPU-3310VL-EPU-3310 Product Page

4 GB RAM

Datasheet VL-EPU-3311View VL-EPU-3311 Product Training ModulesVL-EPU-3311 Product Page

4 GB RAM

Datasheet VL-EPU-3312View VL-EPU-3312 Product Training ModulesVL-EPU-3312 Product Page


SkyLake
Core i3-6100U 2.3 GHz
Dual-Core


8 GB RAM



8 GB RAM




SkyLake
Core i5-6300U 2.4 GHz
Dual-Core
      16 GB RAM 16 GB RAM
SkyLake
Core i7-6600U 3.4 GHz
Dual-Core
      16 GB RAM
32 GB RAM
16 GB RAM
32 GB RAM

SkyLake
Core i5-6442EQ 1.9 GHz
Quad-Core


16 GB RAM

Datasheet VL-EPU-4562VL-EPU-4562 Product Page

SkyLake
Core i7-6822EQ 2.0 GHz
Quad-Core


16 GB RAM

Datasheet VL-EPU-4562VL-EPU-4562 Product Page

32 GB RAM

Datasheet VL-EPU-4562VL-EPU-4562 Product Page



The EPU Story

The EPU (Embedded Processing Unit) story revolves around the flexibility of using a 2-board set to form a complete embedded computer product. Creating separate CPU and I/O modules, which are then tightly sandwiched together as a final product, allows for a wide range of advantages compared to a typical single board embedded computer.

The anatomy of an EPU product:

I/O Module

While baseboard design is touted as "easy", in actuality it can take as long as the CPU design. There are multiple high-speed busses that need specific layout and routing rules: PCIe, DisplayPort, SATA, and USB 3.0 to name a few. In addition, each of these signals needs to be validated to the specification over temperature.

CPU Module (COM)

Each CPU module has various I/O functions implemented on the board and the signals routed to the inter-board connector. While there is a base requirement for implemented I/O, there are also many options to the specification that differ in implementation from CPU module to CPU module. VersaLogic does the work to match the on-board CPU I/O with the baseboard I/O and provide the necessary BIOS and API's to ease application development.

Thermal Interface

Thermal Interface Material (TIM's) are used to transfer heat from the hot components to the heat plate. The purpose it to make sure that all components are properly cooled with no reverses heating of components on the board.

Thermal / Mounting System

All EPU's are engineered with a heat plate designed specifically to match the CPU module. This plate provides mounting for other thermal extraction technologies (heat sink, etc.) or directly to a system chassis.

Various Thermal Options

VersaLogic offers several optional thermal management products: bolt-on heat sink, fan for the heat sink, and heat pipe adapter.

Custom BIOS

The BIOS is written to support the functionality of the COM module as well as the I/O and features on the baseboard. There is never finger-pointing as to who is responsible to make the I/O function.

Expansion via Mini PCIe / mSATA sockets

The Mini PCIe card sockets accept a variety of plug-in modules such as Wi-Fi modems, analog to digital converters, GPS receivers, additional Ethernet ports, flash data storage and other small sized plug-in cards for added flexibility.

Custom API Software

The Application Specific Interface (API) is provided that allows access to the I/O on the baseboard that is not supported by the operating system. This allows the software developer to easily access the functionality during initial development. When migrating to a new VersaLogic platform, the API allow easy of software portability.

Various Thermal Options

VersaLogic offers several optional thermal management products: bolt-on heat sink, fan for the heat sink, and heat pipe adapter.

One of the keys to the EPUs success is that the CPU and I/O modules are not sold individually or left to the user to assemble correctly. All units are sold assembled and tested as a fully functional embedded computer. The unit is handled as a single piece, ready to install in your device.

The advantages of VersaLogic’s EPU products include:

  • Standards based
    EPUs are designed using industry standards such as tested and proven connectors, pinouts, signaling, mounting points, etc. This adds to the flexibility and the reliability of the product. Most EPU products are designed around the COM Express standard.
  • Future proof?
    That’s a big claim, but the two-board configuration of EPU products allow either the CPU portion, or the I/O portion, to be easily updated. This greatly simplifies technology migrations of the processor, or changing I/O needs (such as revising your product to add additional features). VersaLogic can deliver a newer generation EPU that is basically a drop-in replacement for your existing unit!
  • Extremely compact
    EPUs are some of the industry’s smallest embedded computers. The 2-board “sandwich” design makes these embedded computers fit where others don’t.
  • Stability
    Eliminate "surprise" system upgrades or redesigns with VersaLogic’s 5+ year product availability guarantee!
  • Dependability
    Take comfort in having VersaLogic’s award winning service, and 40 years of embedded computer expertise behind you.
  • Rugged
    With exacting design and testing, harsh environments are not a challenge for EPU products. All are tested for temperature (-40 to +85C for most products), for shock and vibration (MIL-STD-202G), and hundreds of other validation steps that make EPUs some of the most reliable embedded products on the planet.
  • Modified COTs
    The two-board concept simplifies modifications to meet your I/O needs; whether by configuring existing products the way you want, modifying a COTS item, or creating a customized I/O solution. With the two-board concept these modification come at lower cost and shorter lead time than other types of solutions. Call today for details.
  • Fast Time-To-Market
    All EPU configurations are fully assembled, tested, and production ready. Most versions are available off-the-shelf for immediate shipment. Order one today and spend your time designing your device, not the computer that runs it!
  • Expandable
    Most EPUs feature one or more built-in mini-PCI sockets. These allow plug-in I/O expansion, with devices such as Analog Input, GPS, Ethernet, Serial I/O or Firewire, with almost no increase in board size.
  • Supported
    Software tools shouldn’t be an afterthought if you’re developing a complex product. EPU products are delivered complete with drivers for popular operating systems, and an API package to simplify accessing the on-board I/O devices. Get a jump start on your development!
  • Flexibility
    The two-board concept allows many CPU and I/O combinations to be created for a wider range of products. Get the performance, power, I/O combination that you need!

Myth vs. Reality

Are there other ways to get this degree of flexibility?

Yes. You can “roll your own” EPU-type product using COM modules that are available from a number of suppliers. If you have the R&D resources available, you can design your own I/O “carrier board” to connect with a commercial COM (processor) module, and then have the carrier card manufactured. It takes quite of bit of expertise to design with high speed signals, implement a validation program to make sure the I/O circuits work properly, and create a testing process for the finished board.  Add in some effort for software drivers, BIOS customization, and API code to support your on-board I/O, and you’re almost over the finish line.

Many EPU purchasers started out on a “build-it-yourself” plan, and quickly realized that the challenges and costs and time delays involved are substantial. Purchasing a carefully designed, fully validated EPU product today, is hard to compare to investing a year or two of development effort in hopes that the final in-house design will function as needed.
